1. Product Features:

1. Precise control of movement speed to enhance coating repeatability;

2. The air knife allows adjustment of the airflow angle within a range of-45° to 45°.

3. The equipment is optionally equipped with adjustable coating scrapers, four-sided applicators, and wire rods.

4.4.3 Full-color touchscreen digital interface control system with portable operation;

5. Hard anodized aluminum mirror-polished panel with vacuum adsorption function;

6. The height of the air knife relative to the substrate is adjustable, with a vertical adjustment range of 10-35mm.

2. Product Parameters:

1. Coating speed: 1-50 mm/s;

2. Speed regulation accuracy: 1 mm/s;

3. Travel length: 250mm;

4. Vacuum panel dimensions: 380mm x 210mm;

5. Vacuum adsorption zone: A4;

6. Heating temperature: room temperature to 200℃;

7. Temperature rise rate controllable: 1-10℃/min;

8. Thermal uniformity: ≤±2%;

9. Power input: AC 200V-240V, single-phase, 50Hz, 2.0KW;

10. Vacuum input requirements: 0.06-0.09 Mpa, minimum flow rate above 15 L/min;

11. Program settings: 100 sets of 5-step procedures;

12. Vacuum interface: The rear panel outlet has an outer diameter of 6mm.
